TI LED Driver Integrated Circuit Step Down 40A TPS549D22RVFT

  • 1
  • 2
  • 3

Brand Name : Texas Instruments

Model Number : TPS549D22RVFT

MOQ : 1 piece

Payment Terms : T/T

Delivery Time : 2~8 workdays

Brand : Texas Instruments

Certificate : /

Model : TPS549D22RVFT

MOQ : 1 pc

Price : Negotiated

Delivery : 2~8 workdays

Payment : T/T

Contact Now

PRODUCT DESCRIPTION
TI LED Driver Integrated Circuit Step Down 40A TPS549D22RVFT

Display Driver IC Texas Instruments/TI TPS549D22RVFT

ECAD Module 3D Model
Supply and Demand Status Limited
Fake Threat In the Open Market 67 pct.
Popularity Medium
Win Source Part Number 1112090-TPS549D22RVFT
Case / Package 40-LQFN-CLIP (7x5)
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 125°C (TJ)
Synchronous Rectifier Yes
Frequency - Switching Selectable
Output Current 40A
Maximum Output Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 0.6V
Maximum Input Voltage 22V
Minimum Input Voltage 4.5V
Number of Outputs 1
Output Type Adjustable
Topology Buck
Purpose Step-Down
Status Active
Packaging Reel - TR
Manufacturer Texas Instruments
Categories Integrated Circuits

Description for the TPS549D22The TPS549D22 device is a compact single buck converter with adaptiveon-time, D-CAP3 mode control. It is designed for high accuracy, high efficiency, fast transientresponse, ease-of-use, low external component count and space-conscious power systems.

This device features full differential sense, TI integrated FETs with a high-sideon-resistance of 2.9 mΩ and a low-side on-resistance of1.2 mΩ. The device also features accurate 0.5%, 0.9-V referencewith an ambient temperature range between –40°C and +125°C. Competitive features include: very lowexternal component count, accurate load regulation and line regulation, auto-skip or FCCMmode operation, and internal soft-start control.

The TPS549D22 device is available in 7-mm × 5-mm, 40-pin, LQFN-CLIP(RVF) package (RoHs exempt).

Tags:

277V Display Driver IC

120mA Display Driver IC

TLC591


Product Tags:

TI LED Driver Integrated Circuit



40A Driver Integrated Circuit



TPS549D22RVFT


Buy cheap TI LED Driver Integrated Circuit Step Down 40A TPS549D22RVFT product
